Power Supply Power Supply Power Supply Power Supply 240W 80 PLUS – Active PFC Power Supply. 80 PLUS® rating efficiency. No line switching required.
Ports Ports Ports Ports USB USB USB USB 6 USB 2.0 (2 front, 4 rear)
Plus 4 additional USB+POWER; 3 @ 12V, 1 @ 24V
Serial Serial Serial Serial 2 RS232 individually configurable to power 5V & 12 V. COM1 can be
configured for 5V, 9V, and 12V
Plus 2 additional RS232 on some models via PCI card. Individually
configurable to power 5V and 12V
Parallel Parallel Parallel Parallel 1
PS/2 PS/2 PS/2 PS/2 2
Video Video Video Video 1
Audio Audio Audio Audio 2, line in and line out
NIC NIC NIC NIC RJ-45
Support for Multi- Support for Multi- Support for Multi- Support for Multi-
Monitor*
Monitor* Monitor* Monitor*
available via HP ADD2 SDVO DVI-D Adapter
* The rp5700 supports normal (or non-reversed) layout (Advanced Digital Display 2) adapter cards
inserted into the SDVO (Serial Digital Video Output) connector on the system board. This connector has
the physical appearance of a PCIe- x16 connector; however, conventional PCIe cards are not supported
in this connector.
Chipset Chipset Chipset Chipset Intel Q963 with ICH8-RAID
Processor and Processor and Processor and Processor and
Speed*
Speed* Speed* Speed*
One of the following
Intel Core2 Duo Processor E7400 (2.80-GHz, 3-MB L2 cache, 1066-MHz FSB)
Intel Core2 Duo Processor E6400 (2.13-GHz, 2-MB L2 cache, 1066-MHz FSB)
Intel Pentium Dual-Core Processor E2160 (1.80-GHz, 1-MB L2 cache, 800-MHz FSB)
Intel Celeron Processor 440 (2-GHz, 512-KB L2 cache, 800-MHz FSB)
* Intel processor numbers are not a measure of performance. Processor numbers differentiate features within each processor family,
not across different processor families.
Memory Memory Memory Memory DDR2 SYNCH DRAM NON-ECC MEMORY DDR2 SYNCH DRAM NON-ECC MEMORY DDR2 SYNCH DRAM NON-ECC MEMORY DDR2 SYNCH DRAM NON-ECC MEMORY
Memory upgrades are accomplished by adding single or multiple DIMMs of the same or varied sizes.
This chart does not represent all possible memory configurations. The rp5700 supports non-ECC DDR2
PC2-5300 (667-MHz) and PC2-6400 (800 MHz) memory.*
HP recommends dual-channel symmetric configurations for maximum performance. HP recommends dual-channel symmetric configurations for maximum performance. HP recommends dual-channel symmetric configurations for maximum performance. HP recommends dual-channel symmetric configurations for maximum performance.
For best performance, add the same amount of total memory to each channel and do not mix speeds.
For dual-channel symmetric performance, the total amount of memory in each channel must be equal. If
speeds are mixed, speed will default to the slowest DIMM.
1-GB DDR2 Synch DRAM 667-MHz or 800-MHz* Non ECC (1 x 1 GB)
2-GB DDR2 Synch DRAM 667-MHz or 800-MHz* Non ECC (1 x 2 GB)
2-GB DDR2 Synch DRAM 667-MHz or 800-MHz* Non ECC (2 x 1 GB)
3-GB DDR2 Synch DRAM 667-MHz or 800-MHz* Non ECC (3 x 1 GB)
4-GB DDR2 Synch DRAM 667-MHz or 800-MHz* Non ECC (4 x 1 GB)
4-GB DDR2 Synch DRAM 667-MHz or 800-MHz* Non ECC (1 x 4 GB)
QuickSpecs
HP rp5700 Long Lifecycle Desktop PC HP rp5700 Long Lifecycle Desktop PC HP rp5700 Long Lifecycle Desktop PC HP rp5700 Long Lifecycle Desktop PC
Standard and Configurable Components
DA - 12758 North America — Version 26 — March 22, 2011 Page 5
