ADD2 SDVO DVI-D ADD2 SDVO DVI-D ADD2 SDVO DVI-D ADD2 SDVO DVI-D
Adapter
Adapter Adapter Adapter
Form Factor Form Factor Form Factor Form Factor Low-profile card (full-height (ATX) and low-profile brackets included in kit)
Dual head support Dual head support Dual head support Dual head support Yes
Host Interface Connector Host Interface Connector Host Interface Connector Host Interface Connector Mechanically compliant with PCI-e standard
Complies with the Intel ADD2 and Intel Serial Digital Video Output
(SDVO) specifications
Dot Clock Dot Clock Dot Clock Dot Clock 165 MHz maximum
Display Modes Display Modes Display Modes Display Modes Supports display modes that require up to 165-MHz bandwidth on the link,
as shown in the following table.
Resolutions Supported Resolutions Supported Resolutions Supported Resolutions Supported Resolutions Resolutions Resolutions Resolutions 60-Hz LCD 60-Hz LCD 60-Hz LCD 60-Hz LCD 60-Hz 60-Hz 60-Hz 60-Hz 75-Hz 75-Hz 75-Hz 75-Hz 85-Hz 85-Hz 85-Hz 85-Hz
Blanking 5% reduced GTF GTF GTF
640 x 480 VGA Yes Yes Yes Yes
800 x 600 SVGA Yes Yes Yes Yes
1024 x 768 XGA Yes Yes Yes Yes
1280 x 1024 SXGA Yes Yes No No
1600 x 1200 UXGA Yes Yes No No
1920 x 1200 Yes No No No
Color Depth Color Depth Color Depth Color Depth All modes support 8-bpp, 16-bpp, and 24-bpp color depths (up to 16.7
million colors)
NVS 290 x1 PCIe NVS 290 x1 PCIe NVS 290 x1 PCIe NVS 290 x1 PCIe
Graphics Card
Graphics Card Graphics Card Graphics Card
Bus type Bus type Bus type Bus type PCIe x1
Low profile, both ATX and low profile brackets included
Graphics Controller Graphics Controller Graphics Controller Graphics Controller Integrated Quadro 290 2D graphics processor unit (GPU)
Core clock 460MHz
Memory Memory Memory Memory 256 MB DDR2, 64 bit wide, Memory clock 400MHz
Connector Connector Connector Connector Single high-density DMS-59 Flex Connector
Dimensions Dimensions Dimensions Dimensions Low-profile, 2.586 x 6.6 in (6.57 x 16.76 cm)
Multi-monitor support Multi-monitor support Multi-monitor support Multi-monitor support Dual analog or digital (Single Link DVI) monitors
(DVI support requires optional DVI cable kit DL139A)
RAMDAC RAMDAC RAMDAC RAMDAC Dual 350 MHz (integrated)
Maximum pixel clock Maximum pixel clock Maximum pixel clock Maximum pixel clock 350 MHz
Overlay planes Overlay planes Overlay planes Overlay planes One 1-bit Video overlay plane
High-defintion Video High-defintion Video High-defintion Video High-defintion Video
Processor (HDVP)
Processor (HDVP) Processor (HDVP) Processor (HDVP)
Full screen, full frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling
Display options Display options Display options Display options Supports two displays via included DMS-59 to dual VGA cable or 2 DVI
monitors via optional DMS-59 to dual DVI-I single-link connectors cable kit
part number: DL139A
Resolutions supported Resolutions supported Resolutions supported Resolutions supported
QuickSpecs
HP rp5700 Long Lifecycle Desktop PC HP rp5700 Long Lifecycle Desktop PC HP rp5700 Long Lifecycle Desktop PC HP rp5700 Long Lifecycle Desktop PC
Technical Specifications - Graphics
DA - 12758 North America — Version 26 — March 22, 2011 Page 25
