Safety Safety Safety Safety UL recognized to UL 1950, 3rd edition (U.S. and Canada); IEC 950 (TUV,
NEMKO, DEMKO, SEMKO); CE Mark, EC 950 (TUV, NEMKO, DEMKO,
SEMKO, CE mark
EMC EMC EMC EMC FCC Part 15, IC ES003, EN 55022, 3rd edition, EN 55024, annex A, EN
61000-4-6, EN 61000-4-8
Telecom Telecom Telecom Telecom FCC Part 68, IC-CS-03 (Canada); Worldwide PTT approvals
Not available in Korea or the Republic of South Africa.
Other Other Other Other The SV92EX device is packaged in a 32-pin micro leadless chip carrier
(MLCC). The SV92EX is fully compliant with the PCI Express revision 1.1
specification. WHQL approved; ASPM compliant.
HP Wireless 802.11b/g/n HP Wireless 802.11b/g/n HP Wireless 802.11b/g/n HP Wireless 802.11b/g/n
PCIe
PCIe PCIe PCIe
Dimensions (LxH) Dimensions (LxH) Dimensions (LxH) Dimensions (LxH) 3.3 x 4.7 inches (8.5 x 12 cm)
Weight Weight Weight Weight 0.08 pounds (40 g)
Controller Controller Controller Controller Ralink RT2790
System interface System interface System interface System interface PCIExpress x1
Network standard Network standard Network standard Network standard 802.11 b/g/n
Frequency band Frequency band Frequency band Frequency band 2.400 - 2.497 GHz
Operating temperature Operating temperature Operating temperature Operating temperature 14° to 149°F, operating (-10° to 65°C, operating)
Storage temperature Storage temperature Storage temperature Storage temperature -40° to 176°F, non-operating (-40° to 80°C, non-operating)
Humidity Humidity Humidity Humidity 10-90% operating
5-95% non-operating
Operating voltage Operating voltage Operating voltage Operating voltage 3.3V +/- 9%
12V +/- 8%
Power consumption Power consumption Power consumption Power consumption Platform/WLAN Mode Power Consumption
Maximum Power
Consumption 10 Watts
Transmit Only 4 Watts maximum averaged power over 1
second
Transmit Packet or Active
Scanning 1000 mA peak current for 100 microseconds or
longer
Receive Only Mode or Idle
without IEEE PSP mode
enabled 3 Watts maximum averaged over 1 second
Idle, with IEEE PSP mode
enabled 1.0 Watts maximum averaged over 1 second
Transmit Disabled (turned
off in software) 50 mW maximum, averaged over 1 second
Platform in S3 or S4
(power removed from Low
Profile PCI Express Card) 5 mW maximum, averaged over 1 second
Output power Output power Output power Output power
(approximately) 802.11b modes 802.11b modes 802.11b modes 802.11b modes 802.11g modes 802.11g modes 802.11g modes 802.11g modes EWC modes EWC modes EWC modes EWC modes
+19 dBm +/- 1.0 dB
maximum +17 dBm +/- 1.0 dB
maximum +17 dBm +/- 1.0
dB maximum (total
power in all transmit
chains)
QuickSpecs
HP rp5700 Long Lifecycle Desktop PC HP rp5700 Long Lifecycle Desktop PC HP rp5700 Long Lifecycle Desktop PC HP rp5700 Long Lifecycle Desktop PC
Technical Specifications - Communications
DA - 12758 North America — Version 26 — March 22, 2011 Page 20
