Heat & Glo • Crescent II • 2083-902 Rev. L • 7/08 50
C. Service Parts List CRESCENT II
IMPORTANT THIS IS DATED INFORMATION: When Requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
Log Set Assembly LOGS-CRESCENTII Y
1 Small Log SRV2083-185 N
2 Nailing Tab 2083-212 N
3 Bracket, Glass 2083-234 N
4 Orange Film (Kapton Lens)
Pre 0021179425 2083-180 N
Post 0021179425 2083-280 N
5 Glass, Light Box
Pre 0021179425 SRV2083-135 N
Post 0021179425 SRV2083-235 N
6 Gasket, Light box 2083-232 N
7 Glass Door Assembly GLA-CRESCENTII Y
8
Regulator Assembly NG 2083-062 Y
Regulator Assembly LP 2083-063 Y
9
Valve NG 750-500 Y
Valve LP 593-501 Y
10 Valve Bracket 2083-233 N
11 Flex Tube 2073-007 Y
12
Pilot Assembly NG 2090-012 Y
Pilot Assembly LP 2090-013 Y
13 Control Module 593-592 Y
14 Circuit Board 2083-030 Y
16 3V Adaptor Plug 593-593A Y
15 Wall Switch Wire (4 Lead) 2083-031 Y
17 12V Adaptor 2083-022 Y
18 Junction Box 4021-013 Y
Orifi ce NG (#52C) 582-852 Y
Orifi ce LP (#61C) 582-861 Y
Flue Restrictor 2083-206 N
Glass Latch Assembly 386-122A Y
Lava Rock Bag 705-420 N
Light Bulb 700-540 Y
Solenoid-110 Volt HI/LO (NG only) HTI-17-006 Y
Teco-sil 2083-790 N
Wall Switch and Cover Plate 4041-128 N
Wire Assembly 593-590A Y
Conversion Kit NG NGK-CRESCENTII Y
Conversion Kit LP LPK-CRESCENTII Y
Pilot Orifi ce NG 593-528 Y
Pilot Orifi ce LP 593-527 Y
Regulator NG NGK-DXV Y
Regulator LP LPK-DXF Y
