Number of Drives

6-3 Part Number

146205-B21

146205-B23

146205-B24

146205-B25

146205-B26

146205-B27

146205-B28

1. Can be expanded to two TZ89N-AV drives with part number DS-TL892-UA.
2. A DS-TL890-NE/NG MiniLibrary Expansion Unit can be connected to up to three DS-TL891-NE/NG drive units to manage the drives and cartridges in all
connected units. A DS-TL800-AA pass through mechanism is required for the second and third DS-TL891-NE/NG.
3. Can be expanded to two DLT 35/70 drives with part number 120878-B21.
4. The MiniLibrary Expansion Unit can be used to control the drives and cartridges of up to five drive and data units. A MiniLibrary Pass-Through
Mechanism, part number 120880-B21, is needed for each additional unit beyond the first drive unit.
5. Can be expanded to two DLT 20/40 drives with part number 128671-B21.
6. An upgrade kit to add one DS-TZ89N-VA tape drive.
7. An upgrade kit to add one 35/70 DLT tape drive.
8. Can be upgraded by the addition of a single or multiple 35/70 DLT tape drives with part number 146209-B21.

NOTE:

NOTE: The TL881, TL891, TL893, TL894, TL895, TL896, HP 20/40-GB DLT Tape Drive, HP 40/80 GB DLT Tape Drive, and ESL9326D Enterprise Library are
supported with both the KZPSA and KZPBA-CB/CC adapters. All other SCSI tape device and media changer support is provided with KZPSA adapters only.
NOTE:

NOTE:

NOTE: The TL891 Mini Library, TL895 Automated Tape Library, and the ESL9326D Enterprise Library are also supported on a Fibre Channel storage bus
with the KGPSA-BC and KGPSA-CA adapter.
NOTE:

NOTE:

NOTE: The HP Fibre Channel Tape Controller and Modular Data Router are Fibre Channel-to-SCSI bridges that allow a SCSI tape device to communicate
with other devices on a Fibre Channel.

For a list of tape devices supported by Enterprise Backup Storage, see the Enterprise Backup Storage documentation.

Supported Storage Boxes

TruCluster Server supports the following storage boxes:

Storage Box

Description

BA350

Single ended, narrow

BA356

Single ended, wide

DS-BA356

Ultra SCSI, SBB shelf

DS-SSL14-RS

4254 Storage Enclosure, dual bus, Ultra2

DS-SL13R-BA

4354 Storage Enclosure, dual bus, Ultra3

3R-A4075-AA (302969-B21)

MSA30SB Single Bus (S/B) Rack Mountable

3R-A4076-AA (302970-B21)

MSA30DB Dual Bus (D/B) Rack Mountable

Supported Parallel SCSI

Supported Parallel SCSI
Array (RAID) Controllers

Array (RAID) Controllers

TruCluster Server supports the following parallel SCSI RAID controllers on shared storage buses. The TruCluster Server
Release Notes provide information regarding supported Array (RAID) controllers firmware revisions.

RAID Controller

RAID Controller
RAID Array 3000 (HSZ22)
HSZ80 Array Controller

NOTE:

NOTE: The following RAID controllers are no longer supported:

SWXRA-Z1 Array Controller (HSZ20)
HSZ40-Bx Array Controller
HSZ40-Cx Array Controller
HSZ50-Ax Array Controller
HSZ70 Array Controller
