Supported Fibre Channel

Supported Fibre Channel
Hardware

Hardware

TruCluster Server supports the following Fibre Channel hardware. For more information on the supported Fibre Channel
solutions, see the TruCluster Server Release Notes and the Cluster Hardware Configuration manual. For a list of supported
Fibre Channel switches, see the S

AN Product Support Tables for the SAN Design Reference Guide

at the following URL:

http://www.hp.com/products/StorageWorks/san/documentation.html

Device

Description

KGPSA-BC

PCI-to-Fibre Channel host adapter

KGPSA-CA

PCI-to-Fibre Channel host adapter

KGPSA-DA

PCI-to-Fibre Channel host adapter

KGPSA-EA (302784-B21, FCA2384)

2Gb PCI or PCI-X to FibreChannel Host Bus Aadapter

HSG60

Array Controller

HSG80

Array Controller

HSV110

Array Controller

XP128/1024

Array Controller

XP512/48

Array Controller

MSA1000 (3R-A4328-AA, 201723-B22)

Storage Works modular SAN array

HSG60 and HSG80 controllers may be contained in many cabinet configurations including MA6000, RA8000, MA8000, ESA12000, EMA12000, and
EMA16000. HSV110 controllers may be contained in many cabinet configurations. Any model of the Enterprise Virtual Array (EVA) product set based on the
HSV110 controller is supported.

For more information on the supported XP array hardware, see the XP/Tru64 Connectivity Streams at the following URLs:

http://www.XP128/1024 Connectivity Streams and Other Documents.com
http://www.XP48/512 Connectivity Streams and Other Documents.com

Fibre Channel Arbitrated

Fibre Channel Arbitrated
Loop Support

Loop Support

TruCluster Server supports Fibre Channel arbitrated loop for clusters with a maximum of two members only. The KGPSA-CA
is the only Fibre Channel adapter supported for arbitrated loop configurations. The DS-SWXHB-07 seven-port Fibre
Channel hub is required to build an arbitrated loop configuration and is restricted to use with DS10, DS20, DS20E, and
ES40 systems. The other AlphaServers including the DS10L and ES45 systems are not supported for arbitrated loop.

Supported SCSI

Supported SCSI
Controllers

Controllers

The systems are connected to shared SCSI buses using an adapter from the following list. The TruCluster Server Cluster
Hardware Configuration manual and Release Notes provide more information regarding SCSI controller configuration,
respectively:

KZPSA - PCI to Fast Wide Differential SCSI-2 adapter
KZPBA-CB/CC - PCI to UltraSCSI wide differential adapter
KZPEA-DB

- LVD Multimode U3 PCI SCSI Adapter

NOTE:

NOTE: KZPEA only supported for shared bus with one or two hosts. TruCluster V5.1B-1 Initial Patch Kit (IPK) is required.

Supported SCSI Signal

Supported SCSI Signal
Converters

Converters

TruCluster Server supports the following SCSI signal converters. The Cluster Hardware Configuration manual provides
information regarding supported SCSI signal converters configuration.

Signal Converter

Description

DWZZA-AA

Standalone unit, single-ended/narrow to differential/narrow

DWZZA-VA

SBB, single-ended/narrow to differential/narrow

DWZZB-AA

Standalone unit, single-ended/wide to differential/wide

DWZZB-VW

SBB, single-ended/wide to differential/wide

DS-DWZZH-03

UltraSCSI hub

DS-DWZZH-05

UltraSCSI hub

3X-DWZCV-BA

HVD to LVD converter

QuickSpecs

HP TruCluster Server V5.1B-1

Storage Hardware Requirements

DA - 11444 Worldwide — Version 4 — December 8, 2003
