Handle, levers & catcher system – Hustler Turf M1 User Manual
Page 47
108548_0711
6-17
Handle, Levers & Catcher System
NOTES:
ITEM
NO.
SERVICE
PART NO.
QTY.
DESCRIPTION
1
51027-268-
1
HANDLE LOWER
2
51027-280-
1
HANDLE UPPER
3
11095-172
1
LEVER
4
36110-102
1
BUTTON
5
11049-109
1
SLIDE PLATE
6
64014-336
1
SHAFT
7
376L-0612
1
TRUSS SCREW
8
71203-135
1
ARM C.P.
9
76007-183
1
BUSHING
10
68013-371
1
SPRING
11
31056-127
1
GIB-HEADED PIN
12
576V-0600
1
PUSH NUT
13
68013-392
1
SPRING
14
11109-111
1
LINK
15
61023-190
1
SLEEVE
16
64014-337
1
SHAFT
17
812V-0800
1
C-SNAP RING
18
613L-0800
2
WASHER
19
71161-120-09
1
LEVER ASSEMBLY
20
N/A
1
LEVER (INCLUDES ITEMS 21 & 22)
21
76007-131
1
BUSHING
22
76007-191
1
BUSHING
23
68013-391
1
SPRING
24
91010-169
1
THROTTLE LEVER
25
61003-113
1
THRUST PLATE
26
68013-356
1
SPRING
27
31058-168
1
HEX NUT
28
11095-117
1
LEVER
29
31062-109
1
PRE-COAT LOCK BOLT
30
31057-281
1
HEX BOLT
31
68036-125
1
WASHER
32
563L-0600
1
U-HEX CAP NUT
33
71285-109
1
HOLDER C.P.
34
68013-161
1
SPRING
35
71900-796
1
COVER ASSEMBLY
36
470L-0514
2
TAPPING SCREW
37
71900-845
1
BOLT SET
38
569L-0800
4
FLANGE NYLON NUT
39
31057-256
2
HEX BOLT
40
583L-0800
6
FLANGE CAP NUT
41
71900-846
1
BAR SET
42
11012-132
2
HANGER BAND
43
31057-181
2
HEX BOLT
44
68028-118
3
WIRE BAND
45
91003-125
1
CONTROL CABLE SPD
46
91003-180
1
CONTROL CABLE DRV
47
91001-329
1
THROTTLE WIRE
48
91003-169
1
CONTROL CABLE BBC
49
11062-178
1
FRAME C.P.
50
36098-155
1
GRASS BAG C.P.
51
41003-201
1
TUBE
52
68028-119
2
WIRE BAND
53
36080-156
1
RUBBER SHEET
