Mower deck assy – Hustler Turf M1 User Manual
Page 35
108548_0711
6-5
Mower Deck Assy
NOTES:
ITEM
NO.
SERVICE
PART NO.
QTY.
DESCRIPTION
1
51043-151-107
1
HOUSING MOWER DECK
2
36068-204
1
GUARD
3
51090-117-09
2
PROTECTOR
4
342L-0616
5
FLANGE BOLT
5
512L-0600
4
HEX NUT
6
36065-180
1
COVER
7
342L-0612
12
FLANGE TAPPING BOLT
8
11006-155
1
STAY C.P.
9
11113-407
1
STAY
10
11113-292
1
STAY
11
36068-196-49
1
GUARD REAR DOOR
12
36080-149
1
RUBBER SHEET
13
64014-324
1
SHAFT
14
68013-336
1
SPRING
15
71082-111
1
FAN ASSY (INCLUDES ITEMS 16–19)
16
51125-103
1
FAN
17
11102-151
1
HOLDER
18
31062-169
4
PRE-COAT LOCK BOLT
19
579L-0600
4
FLANGE BOLT
20
61024-208
1
SPACER
21
91014-189
1
BLADE STD M-1
22
31057-197
2
HEX BOLT
23
31057-243
4
HEX BOLT
24
61024-142
3
SPACER
25
71067-106
1
BRAKE ASSY
26
91097-101
1
UNIVERSAL JOINT
27
812V-2000
1
C-SNAP RING FOR SHAFT
28
717B-0418
1
PARALLEL PIN
29
64014-339
1
SHAFT
30
91049-129
1
CONNECTOR
31
68036-280
2
WASHER
32
816V-0800
1
E-SNAP RING
33
36065-438
1
COVER
34
51116-149
1
LEFT HANDLE BRACKET
35
51116-167
1
RIGHT HANDLE BRACKET
36
31057-255
4
HEX BOLT
37
512L-0800
4
HEX NUT
38
11113-429
1
RS STAY
39
11113-428
1
LS STAY
40
31057-181
2
HEX BOLT
41
11113-415
2
STAY
42
71008-431
1
GEAR CASE ASSY
43
711V-0522
2
SPRING PIN
44
733L-1000
1
SNAP PIN
45
94401-16150
1
WOODRUFF KEY
