Wheel breakdown – Hustler Turf M1 User Manual
Page 37
108548_0711
6-7
Wheel Breakdown
NOTES:
ITEM
NO.
SERVICE
PART NO.
QTY.
DESCRIPTION
1
71041-144
2
WHEEL ASSEMBLY (INCLUDES ITEMS 2–4)
2
N/A
2
TIRE—(NOT SERVICED SEPARATELY)
3
N/A
2
WHEEL—(NOT SERVICED SEPARATELY)
4
916B-6002
8
BEARING
5
11086-119
2
STOPPER
6
61003-112
2
THRUST PLATE
7
31034-137
2
PIN
8
68036-270
2
WASHER
9
68036-146
2
WASHER
10
71158-104
1
RATCHET ASSEMBLY RIGHT (INCLUDES ITEMS 11–13)
11
N/A
2
HOLDER—(NOT SERVICED SEPARATELY)
12
N/A
4
PIN—(NOT SERVICED SEPARATELY)
13
N/A
2
SPRING—(NOT SERVICED SEPARATELY)
14
71158-103
1
RATCHET ASSEMBLY LEFT (INCLUDES ITEMS 11–13)
15
68036-275
2
WASHER
16
31057-181
4
HEXAGON BOLT
17
68036-101
6
WASHER
18
11006-151
1
STAY C.P. REAR LEFT
19
11006-152
1
STAY C.P. REAR RIGHT
20
342L-0612
2
SELF-TAPPING FLANGE BOLT
21
31057-255
2
HEXAGON BOLT
22
584L-0800
4
U-FLANGE NUT
23
71122-110
1
LEFT ADJUSTER ASSY (INCLUDES ITEMS 24–26)
24
11142-125
1
ADJUSTER REAR LEFT
25
11102-228
2
HOLDER
26
916B-6202
2
BEARING
27
71122-111
1
RIGHT ADJUSTER ASSY (INCLUDES ITEMS 25, 26 AND 28)
28
11142-126
1
ADJUSTER REAR RIGHT
29
11150-105-09
1
ADJUST LEVER
30
36061-121
4
KNOB
31
613L-0800
2
WASHER
32
569L-0800
2
FLANGE NYLON NUT
33
71041-135
2
WHEEL ASSEMBLY (A.W.) (INCLUDES ITEMS 4, 34 AND 35)
34
N/A
2
TIRE—(NOT SERVICED SEPARATELY)
35
N/A
2
WHEEL—(NOT SERVICED SEPARATELY)
36
11083-332
2
COLLAR
37
51113-119
2
RING
38
11006-153
1
STAY C.P. FRONT LEFT
39
11006-154
1
STAY C.P. FRONT RIGHT
40
11153-114-102
1
BUMPER FRONT
41
335L-0625
6
FLANGE BOLT
42
569L-0600
6
FLANGE NYLON NUT
43
11142-129
1
ADJUSTER FRONT LEFT
44
11142-130
1
ADJUSTER FRONT RIGHT
45
11150-109-09
2
ADJUST LEVER
46
68013-393
4
SPRING
47
68007-105
A/R
SHIM
48
11113-418
1
STAY LEFT
49
11113-417
1
STAY RIGHT
