Brake assembly – Hustler Turf M1 User Manual
Page 39
108548_0711
6-9
Brake Assembly
NOTES:
ITEM
NO.
SERVICE PART
NO.
QTY.
DESCRIPTION
1
71067-106
1
BRAKE ASSEMBLY
2
19512-883-000
2
FAN COLLAR
3
72600-va4-010
1
HOLDER ASSEMBLY
4
72613-va4-000
2
BLADE HOLDER BUSHING
5
75090-va4-030
1
CONTROL ASSEMBLY
6
75100-va4-010
1
BRAKE C.P.
7
75110-VA4-000
1
BALL RETAINER C.P.
8
75182-VA3-j00
2
CLUTCH RETURN SPRING
9
90014-952-000
2
FLANGE BOLT
10
90021-VA4-000
3
SPECIAL BOLT
11
90409-952-000
1
WASHER
12
90501-952-010
1
THRUST WASHER
13
75130-VA4-000
1
BRAKE DISK
14
75132-VA4-000
3
BRAKE HOLDER SPRING
15
75183-VA3-j00
1
CLUTCH SPRING
16
75150-VA3-j01
1
DRIVEN DISK C.P.
17
94401-16150
1
WOODRUFF KEY
18
90105-960-003
1
BOLT 10 X 25
