Hustler Turf M1 User Manual
Page 43
108548_0711
6-13
Gear Case—71008-431
NOTES:
ITEM
NO.
SERVICE
PART NO.
QTY.
DESCRIPTION
1
51001-195
1
GEAR CASE
2
51001-196
1
GEAR CASE
3
61002-161
1
OIL SEAL
4
61002-162
2
OIL SEAL
5
61002-163
2
OIL SEAL
6
64024-104
1
SHIFTER SHAFT
7
11104-119
1
ARM
8
320L-0525
1
HEXAGON BOLT
9
611L-0500
1
PLAIN WASHER
10
571L-0500
1
FLANGE NUT
11
61003-109
1
THRUST PLATE
12
71902-194
1
PINION
13
91097-101
1
UNIVERSAL JOINT
14
812V-2000
1
C-SNAP RING
15
717B-0418
1
PARALLEL PIN
16
11097-106
1
SHIFTER FORK
17
11104-137
1
ARM
18
419U-0630
1
SOCKET SCREW
19
611L-0600
1
PLAIN WASHER
20
661L-0600
1
SPRING LOCK WASHER
21
512L-0600
1
HEXAGON NUT
22
61024-117
1
SPACER
23
78001-162
1
BEVEL GEAR
24
11129-107
1
CLUTCH
25
64014-236
1
SHAFT
26
68013-262
1
SPRING
27
31034-199
1
PIN
28
736U-0320
1
SPRING PIN
29
64014-235
1
SHAFT
30
61024-118
2
SPACER
31
78004-156
1
GEAR
32
78004-155
1
GEAR
33
64014-344
1
SHAFT
34
78012-107
1
GEAR C.P.
35
31034-150
1
PIN
36
812V-2200
1
C-SNAP RING
37
214B-11000
1
O-RING
38
11083-201
2
COLLAR
39
31057-262
1
HEXAGON BOLT
40
68001-110
1
FIBER WASHER
41
11006-191
1
STAY C.P.
42
315L-0625
3
HEXAGON BOLT
43
315L-0635
2
HEXAGON BOLT
44
318L-0612
1
HEXAGON BOLT
45
68007-132
A/R
SHIM
