NOTE: A minimum of 256 MB cache, battery kit, and Smart Array Advanced Pack License Key
upgrade (P/N: 516471-B21) is required to enable RAID 6, 6+0
NOTE: To achieve highest possible stated transfer rate please make sure the firmware on the
drive bays (backplanes) and HP Smart Array controller up to date. Latest firmware is available to
download from HP support web site.
Storage
Diskette Drives
Via USB only
Optical Drives
Optional HP Slim SATA DVD-ROM Optical Drive
Optional HP Slim SATA DVD RW Optical Drive
NOTE: Support in 4, 8, and 12 drive models. Optical drives can only be
installed in 12 drive model and 25SFF drive bay system with rear option
kit (P/N 515826-B21).
Drive Bays
Up to 14 Hot Plug SAS/SATA 3.5" drives
Up to 25 Hot Plug SAS/SATA 2.5" drives
NOTE: 4 Drive Models are Non-Hot Pluggable. Smart Array Controller
must be added for Hot Plug drive capability. 4 Drive Models can be
upgraded with the addition of a Smart Array Controller and a SAS/SATA
Multi-lane cable (496013-B21).
NOTE: The addition of a Smart Array Controller requires the addition of
a SAS/SATA Multi-lane cable (P/N 496013-B21).
Maximum Internal
Storage
Hot Plug 3.5" SATA
28.0TB (14 x 2TB)
Hot Plug 3.5" SAS
28.0TB (14 x 2TB)
Hot Plug 2.5" SATA
12.5TB (25 x 500GB)
Hot Plug 2.5" SAS
12.5TB (25 x 500GB)
Interfaces
Network RJ-45
(Ethernet)
2 10/100/1000 NIC ports (plus 1 dedicated for the HP ProLiant Lights
Out 100i Remote Management)
Serial
1
Graphics
1
USB
5 total ports: (2) front, (2) rear, (1) optional internal
NOTE: In order to connect a USB device internally, the internal USB
Cable G6 Kit must be used (P/N 536769-B21).
NOTE: Please see the following URL for additional information
regarding USB support:
Graphics
32MB* shared supporting all display resolutions up to 1600x1200 16bpp@75Hz
NOTE: 8MB is dedicated to video memory.
Form Factor
Rack (2U), (3.5 in/8.89 cm)
Embedded
Manageability
HP Lights-Out 100
(LO100) Advanced
HP Lights-Out 100, simplifies server setup, control, and lights-out
remote administration of ProLiant 100 Series servers and functions
without additional software. It can be accessed from any location via
LAN or Internet and works hand-in-hand with HP Systems Insight
Manager (SIM), helping customers unlock the value of the ProLiant
platform and deliver the highest possible quality of IT service to the
QuickSpecs
HP ProLiant DL180 Generation 6
Standard Features
