Connecting S/PDIF digital audio
The docking station provides an S/PDIF digital audio jack for an optional digital audio connection. A
coaxial digital audio cable (purchased separately) and an audio receiver (television or stereo) with a
coaxial digital audio port is required to fully enable this feature.
To connect digital audio:
1. Connect one end of a coaxial digital audio cable (purchased separately) to the orange S/PDIF
digital audio jack on the rear panel of the docking station (1).
2. Connect the other end of the cable to the digital audio jack on your television or stereo equipment
(2).
Refer to your television or stereo equipment user guide for the jack name and location.
NOTE: The docking station speakers are muted when a device is connected to the digital audio
jack.
NOTE: Volume is controlled using controls located on the digital audio device.
