5 P43 Pellet Stove
P43 Maintenance - cleaning the Feeder body
Pellet fines will accumulate in the feeder body over
a period of time; therefore, a yearly inspection and
cleaning of this area must be performed.
To clean out fines:
1. Remove the rear cover panels.
. Remove wing nut and feeder cover on the
side of the feeder.
3. Use a vacuum cleaner to remove all fines.
4. Reinstall feed cover, wing nut, and rear
cover panels.
Fig. 39 Pellet Fines will build up in this area
5/16" Hex Head
Screws (2 on
each side)
5/16" Hex Head
Screws (2 on
each side)
The low draft sensor monitors air pressure in the
hopper. Failure to close the hopper lid will result in the
feed motor not running. Depending on the amount of
fines in the fuel being burned, this fitting, known as
the muffler, may need to be cleaned.
Note the location of the muffler and use special
care when cleaning or emptying the hopper.
