Installing the Interface Card (System Online)
N o t e If you will be installing the new interface card in a slot where another
interface card is not currently installed, skip steps 1 and 3.
1. Disconnect all cables from the interface card you will be removing,
and save them for reconnection when you later install that card again.
2. Connect a grounding wrist strap (one is provided with the interface
card) to your wrist and to the back of the router.
3. If the Swap LED on the interface card you will be removing is not on
(see figure 6), press the adjacent Swap button, and hold it until the
Swap LED turns on (about 1–5 seconds).
Swap
1
HP J2608A
ThinLAN
J 2 4 3 4 A
4S
Figure 6. Swap Button and LED
Installation
Install interface card.
