Optional Network
Cabling Hardware
4Gb Optical
Transceivers (SFPs) Short Wave
4Gb - 150m A7446B
Long Wave - 10 km AE493A
Optical cables LC-LC for between 2/4Gb and 2/4Gb Fibre Channel devices
2 m LC-LC Multi-Mode Fibre Channel Cable 221692-B21
5 m LC-LC Multi-Mode Fibre Channel Cable 221692-B22
15 m LC-LC Multi-Mode Fibre Channel Cable 221692-B23
30 m LC-LC Multi-Mode Fibre Channel Cable 221692-B26
50 m LC-LC Multi-Mode Fibre Channel Cable 221692-B27
LC-SC for between a 1Gb and 2/4Gb Fibre Channel devices
2 m LC-SC Multi-Mode Fibre Channel Cable 221691-B21
5 m LC-SC Multi-Mode Fibre Channel Cable 221691-B22
15 m LC-SC Multi-Mode Fibre Channel Cable 221691-B23
Service and Support
Offerings NOTE: The HP Care Pack service part numbers below for ProLiant BL c-Class
server blades, cover the server blade and all HP branded hardware options
qualified for the server, purchased at the same time or afterwards, internal to the
server.
Hardware Services On-site Service
4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic UE458E
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic UE459E
6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years,
Electronic UE460E
Support Plus 24
Onsite HW support 24x7, 4hr response and Microsoft O/S SW Tech support
offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays,
Electronic UE473E
NOTE: HP Care Pack services for the c7000 and c3000 Enclosure cover the
enclosure, power supplies and fans. HP qualified rack options are covered by
these services when installed within the same rack. HP supported c-Class
enclosure devices including pass thru, Ethernet interconnect and virtual connect
modules are also covered by the c7000 and c3000 enclosure Care Pack
services.
NOTE: SAN/Fabric switches for the HP c-Class BladeSystem are not covered
under the c7000 and c3000 enclosure Care Packs, SAN/Fabric switches carry
separate Care Packs. SAN/Fabric Switch Care Pack service level support should
always be uplifted to match existing storage or server service level.
Hardware Services On-site Service
Next Business Day On-site Service, 5-Day x 9-Hour Coverage, 3 Years,
Electronic
NOTE: Uplifts the Ethernet devices to the same level of service as the c-class
enclosure
UE477E
4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic UE478E
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic UE479E
6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years,
Electronic UE480E
Installation & Start-up Services
QuickSpecs HP 4Gb Virtual Connect Fibre Channel Module for c-
Class BladeSystem
Related Options
DA - 12673 Worldwide QuickSpecs — Version 5 — 10-1-2007 Page 9
