Shipping Dimensions Length 352.55mm (13.88 in)
Width 270.00mm (10.63 in)
Height 120.65mm (4.75 in)
Shipping Weight 2.0Kg (4.4lbs)
Product Specifications
Hardware Performance Up to 800 MBps throughput per port
Maximum frame size 2148 bytes (2112 byte payload)
Bandwidth 106 MB, Full Duplex @ 1-Gbps
212 MB, Full Duplex @ 2-Gbps
426 MB, Full Duplex @ 4-Gbps
Aggregate Bandwidth Up to 8.52 GB, Full Duplex
Fabric Latency (intra-
switch) 1-Gbps to 1-Gbps < 0.6 µsec
2-Gbps to 2-Gbps < 0.4 µsec
4-Gbps to 4-Gbps < 0.2 µsec
Number of Fibre
Channel Ports 4 external 1/2/4-Gbps ports
16 internal 1/2/4-Gbps ports
External Port Type Configured as Fabric port (F_Port),
1Gb, 2Gb or 4Gb auto- negotiating SFP ports
Internal Port Type Configured as Fabric Node port (N_Port),
1Gb, 2Gb or 4Gb auto- negotiating
Classes of Service Class 2 and Class 3 Fibre Channel services
Scalability Does not contribute to the total switch limit. See the SAN Design Guide
for latest supported configurations.
Buffer Credits 8 buffer credits per port, ASIC embedded memory
Connectors and
Cabling SFP optical hot-pluggable transceiver with LC connector
Short-Wavelength Laser (SWL) up to 500m (1,640 ft.)
Long-Wavelength Laser (LWL) up to10km
Indicators Module locator (UID)
Module status
Link and Activity
Port Configuration Status
Dimensions Length 10.5in (267.7mm)
Width 7.5 in (92.79mm)
Height 1.1 in (27.94mm)
Weight 1.27Kg (2.8 Lbs)
Environmental Ranges Specification 10C to 35C (50F to 95F)
Temperature Range
Operating 10C to 35C (50F to 95F)
Shipping Shipping -40C to 60C (-40F to 140F)
Storage -20°C to 60°C (-4F to 140°F)
Maximum wet bulb
temperature 30C (80F)
Relative humidity
(noncondensing)
**
Operating 10% to 90%
Shipping 10% to 90%
Storage 10% to 95%
Specification 10C to 35C (50F to 95F)
Power Specification 12V @ 3A (36 W)
QuickSpecs HP 4Gb Virtual Connect Fibre Channel Module for c-
Class BladeSystem
Technical Specifications
DA - 12673 Worldwide QuickSpecs — Version 5 — 10-1-2007 Page 11
