HP BladeSystem c3000 Enclosure - Front View
1. Device Bays 1 thru 8 4. Insight Display
2. Enclosure DVD Drive 5. Active Onboard Administrator
3. Standby Onboard Administrator (reserved for Future)
HP BladeSystem c3000 Enclosure - Rear View
1. Local KVM interface (reserved for future) 7. iLO/Onboard Administrator Port
2. Interconnect Bay 1 8. iLO/Onboard Administrator Port 2 (reserved for future)
3. Active Cool Fans 9. Power Supplies
4. Interconnect Bay 2 10. Interconnect Bay 4
5. Enclosure Up-link and Service Port 11. Interconnect Bay 3
6. Enclosure Down-link
QuickSpecs HP 4Gb Virtual Connect Fibre Channel Module for c-
Class BladeSystem
Supported Products
DA - 12673 Worldwide QuickSpecs — Version 5 — 10-1-2007 Page 4
