Page 21 SKU 94564 For technical questions, please call 1-800-444-3353.
• Speed Rating- The speed rating denotes the speed at which a tire is designed to be driven for ex-
tended periods of time. This does not indicate that the
vehicle or rims can safely reach or maintain that speed.
These ratings are listed to the right. (The markings on
the example tire diagram show M. The markings on your
tire may differ.) Note: You may not find this information
on all tires because it is not required by law.
Tire Ply Composition and Materials Used
• - The num-
ber of plies indicates the number of layers of rubber-
coated fabric in the tire. In general, the greater the number of plies, the more weight a tire can support.
Tire manufacturers also must indicate the materials in the tire, which include steel, nylon, polyester,
and others.
Maximum Permissible Inflation Pressure
• - This number is the greatest amount of air pressure that
should ever be put in the tire under normal driving conditions.
Tire Inflation and Load Limit
Tire and Loading Information Placard
TIRE AND LOADING INFORMATION
The weight of cargo should never exceed 779 kg or 1720 lb.
TIRE SIzE COLD TIRE PRESSURE SEE OWNER’S
MANUAL FOR
ADDITIONAL
INFORMATION.
FRONT 5.30-12 550 kPa, 80 PSI
REAR NONE NONE
SPARE NONE NONE
09g
MODEL
94564
Tire and Loading Information Placard Location
The Tire and Loading Information Placard displays the cold tire inflation pressure
and the load limit for this vehicle. See the Tire Care section starting on the following page
for an explanation of tire pressure and see the Vehicle Load Limit section following that
for an explanation of load limit.
Code MPH
F 50
G 56
J 62
K 68
L 75
M 81
Code MPH
N 87
P 94
Q 100
R 106
S 112
T 118
Code MPH
U 124
H 130
V 149
Z 149
W 168
Y 186
Tire Speed Rating Codes
REV 09b, 09g
