Page 12 SKU 94564 For technical questions, please call 1-800-444-3353.
Allow all parts to dry completely. b.
Make sure your hands are clean and the bearing packer (not included) is c.
clean.
Place fresh, clean bearing grease in the bearing packer.
d.
With the grease-filled bearing packer in one hand and the Bearings (20) in the e.
other, press the Bearing into the grease, forcing the grease inside the slots in
grease, forcing the grease inside the slots in the Bearing. Continue doing this
until every slot in the Bearing is completely full of grease.
(See Figure G.)
Finish assembling the Hub Assembly as explained below, making sure not to
f.
get dirt or debris on any part of the assembly.
Carefully slide the Hubs (18) over the spindles at each end of the Axle (16). 2.
(See Figure G.)
Insert the Bearings (20) and Flat Washers (O) on the spindles. Screw an M20
3.
Castle Nut (M) tightly onto each spindle. Then back the Castle Nut off slightly so
that the Hubs can just move freely. (See Figure G.)
Insert a 4mm Cotter Pin (T) through the M20 Castle Nut (M) and hole at the end of
4.
each spindle, and spread the Cotter Pins. (See Figure G.)
Fill the Dust Caps (21) with bearing grease. Then, press each Dust Cap onto the
5.
Hubs (18). (See Figure G.)
Grease each Grease Fitting (31) located on the backside of each Hub (18).
6.
(See Figure G.)
Install a Tire/Wheel (19) assembly on each Hub Set (18). Then, secure the Tire/
7.
Wheel assemblies, using the M12 Lug Nuts (L). (See Figure G.)
Note: Use a lug wrench (not included) to tighten the M12 Lug Nuts (in a “star” pattern) to
85 to 90 ft-lb. (See Figure G.)
