Appendix – Harman-Kardon AVR360 User Manual
Page 36
36
APPENDIX
appendix – Default settings
Table A1 – Recommended Source Component Connections
Device Type
AVR 460/AVR 360 Source
Digital Audio Connection
Analog Audio Connection
Video Connections
Cable TV, satellite TV, HDTV
or other device that delivers
television programs
CBL/SAT
HDMI 2
Analog 1
HDMI 2
DVD Audio/Video, SACD, Blu-
ray Disc, HD-DVD player
DVD
HDMI 1
Analog 2
HDMI 1
Media Server, including
Harman Kardon DMC 1000
Media Server
HDMI 4
Analog 5
HDMI 4
TV
TV
Optical 1
Analog 3
Component 1*
Video game console
Game
HDMI 3
Analog 4
HDMI 3
Any audio or video device,
e.g., CD player, camcorder,
cassette deck
AUX
Coax Front
Analog Front
Composite Front (not used for
audio-only devices)
Recorder
Any
Coaxial 2 input and Coaxial
Output
Analog 4 inputs and outputs
Composite input and output
iPod or iPhone
The Bridge III
None
The Bridge III
The Bridge III for photo- and
video-capable iPod and
iPhone models
*Make this connection only when using the TV source for a non-display device. Do not connect your television’s or video display’s video output to the AVR at any time.
Table A2 – Source Setting Defaults
Cable/Sat
DVD
Media Server
Radio
TV
Game
AUX
The Bridge
Surround
Modes (Auto
Select)
Logic 7 Movie
Logic 7 Movie
Logic 7 Movie
Logic 7 Movie
Logic 7 Movie
Logic 7 Movie
Logic 7 Movie
Logic 7 Movie
Video Input
HDMI 2
HDMI 1
HDMI 4
N/A
Component 1
HDMI 3
Composite
Front
The Bridge III
Audio Input
HDMI 2
HDMI 1
HDMI 4
N/A
Optical 1
HDMI 3
Analog Front
The Bridge III
Resolution to
Display*
576i/480i
576i/480i
576i/480i
576i/480i
576i/480i
576i/480i
576i/480i
576i/480i
Audio Auto
Polling
Off
Off
Off
N/A
Off
Off
Off
N/A
Zone 2 Audio
Analog 1
Analog 2
Analog 5
Radio
Analog 3
Analog 4
Analog Front
The Bridge III
Dolby Volume
Medium
Low
Medium
Off
Medium
Medium
Low
Medium
* Video output resolution may vary for HDMI connections.
NOTE: This Owner's Manual is the Basic version. It describes all functions essential for the use of the unit. For more in-depth
information, please download the Advanced Functions Manual from the harmankardon.com web site.
All references to the Advanced Functions Manual in the Basic Manual refer to the web-only, additional manual which explains
functions that go beyond the basic use of the receiver. This Advanced Functions Manual also contains more worksheets and the
remote control function list.
