35
ENGLISH
TROUBLESHOOTING GUIDE
proceSSor reSet
If the unit behaves erratically after a power surge, first turn off the Main
Power Switch and unplug the AC power cord for at least 3 minutes. Plug the
cord back in and turn the receiver on. If this doesn’t help, reset the AVR.
NOTE: A system reset erases all user configurations, including video
resolution, speaker and level settings, and tuner presets. After a reset,
reenter all of these settings from your notes in the appendix worksheets.
To reset the AVR 460/AVR 360, place it in Standby mode (press the front-panel
Standby/On Switch so that the Power Indicator turns amber). Then press the
front-panel OK Button for at least 5 seconds until the RESET message appears.
If the receiver does not function correctly after a processor reset, contact an
authorized Harman Kardon service center for assistance. Authorized service
centers may be located by visiting the Web site at www.harmankardon.com.
NOTE: After performing a system reset, wait at least 1 minute before
pressing any Source Selectors.
memory
If the AVR 460/AVR 360 is unplugged or experiences a power outage, it will
retain user settings for up to two weeks.
SYMPTOM CAUSE SOLUTION
Unit does not function when Main
Power Switch is turned on No AC Power • Make certain AC power cord is plugged into a live outlet •
Check whether outlet is switch-controlled •
Display lights, but no sound or
picture Intermittent input connections • Secure all input and speaker connections •
Mute is on • Press Mute Button •
Volume control is down • Turn up volume control •
No sound from any speaker;
PROTECT message appears on
front panel Amplifier is in protection mode due to •
possible short
Check speaker wires for shorts at receiver and speaker ends •
Amplifier is in protection mode due to •
internal problems
Contact your local Harman Kardon service center •
No sound from surround or center
speakers Incorrect surround mode • Select a mode other than Stereo •
Input is monaural • There is no surround information from mono sources •
Incorrect configuration • Check speaker configuration •
Stereo or Mono program material • The surround decoder may not create center- or rear-channel •
information from nonencoded programs
Unit does not respond to remote
commands Weak batteries in remote • Change remote batteries •
Wrong device selected • Press the Setup Button •
Remote sensor is obscured • Make certain front-panel sensor is in line of sight of remote or connect •
an optional remote sensor
Intermittent buzzing in tuner Local interference • Move unit or antenna away from computers, fluorescent lights, •
motors or other electrical appliances
Surround Back Speaker settings
cannot be accessed, and test tone
does not play through Surround
Back Speakers Multizone system has been turned on, and •
the surround back channels were reassigned
to multizone operation
Use the menu system to access the Zone 2 menu and reassign the •
surround back channels to the main room
Unable to activate Program mode
on remote AVR Settings Button not held for at least 3 •
seconds
The selector will light as you initially press it, and go dark as you hold •
it down. Continue to hold it and wait 3 seconds for the selector to
light again
Remote buttons light, but AVR
does not respond Remote is in Zone 2 mode • Slide the Zone Switch at the bottom of the remote to the Zone 1 •
position
Additional information on troubleshooting possible problems with your AVR 460/AVR 360, or installation-related issues, may be found in
the list of “Frequently Asked Questions”, which is located in the Product Support section at www.harmankardon.com.
