C4224-90962 Internal components 169
Table 6-6. Internal components, 3 of 4
KEY # PART # QTY DESCRIPTION
1 RB2-3941-000CN 1 GUIDE, ARM, LEFT
2 RB2-3942-000CN 1 GUIDE, ARM, RIGHT
3 RB2-3947-000CN 1 HOLDER, PAD
4 RF5-2832-000CN 1 ARM, PAD
5 RB2-3960-000CN 1 FLAG, SENSOR
6 RB2-3961-000CN 1 TORSION SPRING
7 RF5-2818-000CN 1 GUIDE, CARTRIDGE, LEFT
8 RF5-2819-000CN 1 GUIDE, CARTRIDGE, RIGHT
9 RF5-2822-000CN 1 ROLLER, FACE-UP
10 RF5-2830-000CN 1 ROLLER, FACE-DOWN
11 RS5-2502-000CN 1 SPRING, COMPRESSION
12 RB2-4016-000CN 1 STOP, SLIDE
13 RY7-5049-000CN 1 GEAR KIT
16 RS6-2122-000CN 1 SPRING, COMPRESSION
17 RG5-4582-000CN 1 PAPER GUIDE PLATE ASS'Y
18 RG5-4587-000CN 1 ARM HOLDER ASS'Y LEFT
18A RB2-4034-000CN 1 MOUNT, ARM
19 RG5-4588-000CN 1 ARM HOLDER ASS'Y RIGHT
19A RB2-4034-000CN 1 MOUNT, ARM
20 RB2-4219-000CN 1 PLATE, GROUNDING
501 XB4-7401-007CN 3 SCREW, TAPPING, PAN HEAD, M4X10
