Keyboard
NOTE:
For a detailed list of available keyboards, see
Sequential part number listing on page 23
.
Description
Spare part number
Keyboard, standard
608222-xxx
Keyboard, QuickWeb
663563-xxx
Before removing the keyboard, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4.
).
5.
Remove the memory/wireless compartment cover (see
6.
Remove the hard drive cover (see
).
Remove the keyboard:
1.
Turn the computer upside down with the front toward you.
2.
Remove the two Phillips M2.5×6.5 screws that secure the keyboard to the computer.
3.
Turn the computer right-side up with the front toward you.
4.
Open the display as far as possible.
5.
Release the top edge of the keyboard by lifting it up to disengage the keyboard from the tabs on
the top cover (1).
6.
Rotate the keyboard over until it rests on the palm rest (2).
