Optical drive
Description
Spare part number
DVD±RW SuperMulti DL Drive (select models only)
677742-001
Optical drive weight saver
660550-00
Before removing the optical drive, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4.
).
5.
Remove the hard drive cover (see
).
Remove the optical drive:
1.
Position the computer upside down with the front toward you.
2.
Remove the Phillips M2.5x5.0 screw (1) that secures the optical drive to the computer.
3.
Use a flat-bladed screwdriver or similar tool to push the drive bracket (2) to release the optical
drive.
4.
Remove the optical drive (3).
5.
If it is necessary to remove the drive bezel, insert the end of a paper clip into the release access
hole (1) in the optical drive bezel. Press in gently until the tray is released.
