Page 67

Reverse this procedure to install the top cover.

Keyboard

NOTE:

The keyboard spare part kit includes a keyboard cable and a keyboard light cable.

For use in country or region:

Spare part number:

For use in country or region:

Spare part number:

Keyboard in natural silver finish:

For use in the Netherlands

665917-B31

For use in Belgium

665917-A41

For use in Portugal

665917-131

For use in Brazil

665917-201

For use in Russia

665917-251

For use in Canada

665917-121

For use in Saudi Arabia

665917-171

For use in Denmark, Finland,
Norway

665917-DH1

For use in Spain

665917-071

For use in France

665917-051

For use in Switzerland

665917-BG1

For use in Germany

665917-041

For use in Turkey

665917-141

For use in Italy

665917-061

For use in the United Kingdom and
Singapore

665917-031

For use in Latin America

665917-161

For use in the United States

665917-001

Before removing the keyboard, follow these steps:

Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.

Disconnect all external devices connected to the computer.

Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.

Remove the battery (see

Battery on page 39

), and then remove the following components:

Subwoofer (see

Subwoofer on page 41

)

Hard drive (see

Hard drive on page 51

)

Top Cover (see

Top cover on page 56

)

Remove the keyboard:

Turn the top cover upside down, with the front toward you.

Remove the five Phillips PM2.5×3.6 screws (1) that secure the keyboard bracket to the top cover.

Slide the keyboard bracket (2) toward the top edge of the top cover until the five tabs (3) on the
bottom edge of the bracket disengage from the top cover.
