Form factor Minitower
Operating System
(choice) Microsoft Windows XP Professional SP2
Microsoft Windows XP Professional SP2 x64 Edition
OR Red Hat Enterprise Linux Workstation 3 Update 5 (support for x86 or EM64T)
OR HP Installer Kit for Linux (includes drivers for 64-bit OS versions on xw9300, xw8200, xw6200,
xw4200)
Color Carbonite/Alloy metallic
System Board Form
Factor E- ATX (12" x 13")
Processor Single or dual AMD Opteron 200 series processors with AMD64 Technology & HyperTransport
CPU Bus Speed
Supported 1 GHz HyperTransport
Standard L2 Cache 1 MB L2 cache per core.
Chipset NVIDIA nForce Professional with AMD-8131 HyperTransport PCI-X tunnel
Memory Expansion Slots 8 DIMMs, 4 slots active for each CPU in the system)
Memory Type Supported DDR (ECC registered)
Memory Speed
Supported
DDR Synch DRAM PC3200 (400 MHz) and PC2700 (333 MHz) Registered ECC
Maximum Memory 32 GB (8 DIMMs slots with 4 GB DIMMS, 8 GB per CPU socket)
Network controller Integrated NVIDIA nForce Professional 10/100/1000 LAN
Audio AC'97
PCI slots 2 PCI-Express (PCIe) x16 graphics
3 full-height PCI-X slots (one 133 MHz, two 100 MHz slots)
1 full-length PCI slot
Scalable Link Interface Yes
Bays Total Bays = 8
Internal Bays Five 3.5 inch bays (4 with acoustic dampening rail assemblies)
External Bays Three 5.25 inch bays. Top two support full depth (210 mm maximum) devices. Bottom bay is
depth restricted to 169mm (including cables). Bays can be converted to internal 3.5" drive
bays using optional bracket.
Floppy drive bay using optional bracket. Consumes 1 - 5.25 bay.
Parallel Port 0
Serial Port 1
Front I/O 2 USB 2.0, Headphone, Microphone, IEEE 1394
Rear I/O 4 USB 2.0, 1 standard serial port, 1 IEEE 1394, PS/2 keyboard and mouse, 1 RJ-45 to integrated
Gigabit LAN, Audio In, Audio Out, Mic In
USB Keyboard Optional
USB Mouse Optional
PS/2 Keyboard 1
PS/2 Mouse 1
Chassis Dimensions
(H x W x D) 17.9 x 8.3 x 20.7 in (45.4 x 21.0 x 52.5 cm)
System weight Minimum config – 42 lb (19 kg)
Standard config – 45 lb (20 kg)
Maximum config – 54 lb (24 kg)
Shipping weight Standard config – 54 lb (24 kg)
Temperature Operating 40° to 95° F (5° to 35° C)
Non-operating -40° to 140° F (-40° to 60° C)
Humidity Operating 8% to 85%
Non-operating 8% to 90%
QuickSpecs
HP xw9300 Workstation
Standard Features - Specs
DA - 12186 Worldwide QuickSpecs — Version 25 — 4.30.2006 Page 8
