HP XW9300 - Manual (Page 43)

HP SpaceMouse Plus
USB Physical
characteristics Dimensions (H x W x D) 7.4 x 4.72 x 1.73 in (18.8 x 12.0 x 4.4 cm)
Cap Diameter 2 x 6.5 x 6.6 mm
Weight 1.5 lb (0.68 kg)
Features Six degrees of freedom motion control
through the X, Y, Z axis (pitch, roll, yaw)
Certified for leading CAD and DCC
applications
Environmental Operating temperature 41° to 140° F (5° to 60° C)
Non-operating
temperature -13° to 158° F (-25° to 70° C)
Operating humidity 10 to 98 % RH (non-condensing)
Non-operating humidity10 to 98 % RH (non-condensing)
Mechanical Buttons 11 programmable (unshifted)
Cap Force Range 0.2 N – 4.5 N
Cap Torque Range 4 Nmm to 100 Nmm
Resolution 8 bit
USB Specifications Connector USB 1.1 or greater
Cable Length 6.56 ft (2 m)
Data Rate 16 msec
Software Drivers
Available Microsoft Windows XP Professional
System Requirements Disk Space 10 MB free disk space
Regulatory Approvals UL, cUL, EN 950, EN 60950, CSA, FCC, CE Mark, TUV, CISPR 22, EN
50082, IEC 1000 4-2, IEC 1000-4-3, AS/NZS, VCCI, BSMI, C-Tick
SpaceBall 5000 (USB) Physical
characteristics Dimensions (H x W x D) 3.0 x 6.0 x 8.4 in (7.6 x 15.2 x 21.3 cm)
Ball Diameter 2.2 in (5.6 cm)
Weight 2.1 lb (9.94 kg)
Features Six degrees of freedom motion control
through the X, Y, Z axis (pitch, roll, yaw)
Certified for leading CAD and DCC
applications
Environmental Operating temperature 50° to 104° F (10° to 40° C)
Non-operating
temperature 43° to 140° F (6° to 60° C)
Operating humidity 8% to 80% (non-condensing at ambient)
Non-operating humidity5% to 80% (non-condensing at ambient)
Mechanical Buttons 12 programmable (unshifted)
Ball Force Range 0.5 - 8.2N/1.8 - 29.5 oz
Ball Torque Range 0.085 – 0.33 oz-in. (6.91 Nmm)
Resolution 10 bits
Serial Specifications Connector USB 1.1 or greater
Cable Length 12.8 ft. (3.9 m)
Data Rate USB model – 16 msec
Flow Control Xon/Xoff (on PS/2 model only)
Software Drivers
Available USB model Microsoft Windows XP Professional
System Requirements Disk Space 10 MB free disk space
QuickSpecs
HP xw9300 Workstation
Technical Specifications - Input/Output Devices
DA - 12186 Worldwide QuickSpecs — Version 25 — 4.30.2006 Page 43
