8 - 2
Image Scanner Report
Scan the barcode below to generate a report for the connected image scan-
ners. The report indicates the port, work group, image scanner name, and
address. To assign a name to your image scanner, refer to
"Menu Command
Syntax" on page 10-1.
Image Scanner Address
Scan the barcode below to determine the address of the image scanner you are
using.
Base Address
Scan the barcode below to determine the address of the base you are using.
Resetting the Standard Product Default Settings:
Current Application Work Group
If you aren’t sure what programming options are in your image scanner, or
you’ve changed some options and want the standard product default settings
restored, scan the
Standard Product Default Settings: Current Application
Group barcode below.
The Menu Commands starting on page 10-6 list the factory default settings for
each of the commands (indicated by an asterisk (*) on the programming pages).
Note: Scanning this barcode also causes both the image scanner and the base
to perform a reset and become unlinked. Refer to "Image Scanner
Modes" on page 1-5 for additional information.
Image Scanner Report
Image Scanner Address
Base Address
Standard Product Default Settings:
Current Application Group
