IMAGETEAM™ 2020/5620 System Manual 10 - 17
PosiCode
Off POSENA0 6-33
*On POSENA1 6-33
A and B On POSLIM0 6-33
A and B and Limited A On POSLIM1 6-33
*A and B and Limited B On POSLIM2 6-33
PosiCode Msg. Length
Minimum (2 - 80) *4 POSMIN## 6-33
Maximum (2 - 80) *48 POSMAX## 6-33
Trioptic Code
*Off TRIENA0 6-34
On TRIENA1 6-34
Codablock F
Default All Codablock F Set-
tings
CBFDFT 6-34
Codablock F
*Off CBFENA0 6-34
On CBFENA1 6-34
Codablock F Msg. Length
Minimum (1 - 2048) *1 CBFMIN#### 6-34
Maximum (1 - 2048) *2048 CBFMAX#### 6-34
Code 16K Default All Code 16K Settings 16KDFT 6-35
Code 16K
*Off 16KENA0 6-35
On 16KENA1 6-35
Code 16K
Minimum (0 - 160) *1 16KMIN### 6-35
Maximum (0 - 160) *160 16KMAX### 6-35
Code 49 Default All Code 49 Settings C49DFT 6-35
Code 49
Off C49ENA0 6-36
*On C49ENA1 6-36
Code 49
Minimum (1 - 81) *1 C49MIN## 6-36
Maximum (1 - 81) *81 C49MAX## 6-36
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page
