74
TECHNICAL & CONSUMER INFORMATION
Specifications
EM5000is
SPECIFICATION
Tuneup Specifications
ITEM MAINTENANCE
Dimensions
Engine
Generator
EAJJ
3.2 2.5 in (82 64 mm)
EM5000is
GX340K1
No other adjustments needed.
EX: 0.20 0.02 mm
IN: 0.15 0.02 mm
5.0 kVA
4.5 kVA
37.5/18.8 A
60 Hz
120/240 V
A
Forced air
Spark plug gap
Valve clearance(cold)
Other specifications
Refer to page: 51
See your authorized
Honda dealer
45.5 in (1,155 mm)
26.4 in (670 mm)
27.2 in (690 mm)
28.0 in (710 mm)
209 lbs (95 kg)
31.9 in (810 mm)
20.6 cu-in (337 cm )
8.0:1
Full transistor
1.2 US qt (1.1 )
4.49 US gal (17.0 )
BPR5ES (NGK)
W16EPR-U (DENSO)
2,400 3,600 rpm
4-stroke, overhead valve, single cylinder
Model
Description code
Length
[Handle in up position]
Width
Height
[Handle in up position]
Dry weight
Model
Engine type
Displacement
[Bore
Stroke]
Compression ratio
Engine speed
Cooling system
Ignition system
Oil capacity
Fuel tank capacity
Spark plug
Type
Rated voltage
Rated frequency
AC output Rated current
Rated output
Maximum output
]
] [
[
Eco-Throttle ON
] [
Specifications may vary according to the types, and are subject to
change without notice.
Without battery
0.028 0.031 in (0.70 0.80 mm)
