Page 47
45
PRODUCT SPECIFICATIONS (continued)
Recommended Signal List (continued)
With RGB input
Signal mode
No
Signal
name
Resolution
Vertical
frequency
(Hz)
Horizontal
frequency
(kHz)
Dot clock
frequency
(MHz)
Remarks
1 640
x
400
70.09
31.47
25.18
2
VGA
640 x 480
59.90
31.47
25.18
3 800
x
600
60.32
37.88
40.00
4
1024 x 768
60.00
48.36
65.00
5
VESA
1280 x 1024
60.02
63.98
108.00
6
1280 x 768
59.89
47.78
79.50
7
VESA
1360 x 768
60.02
47.71
85.50
●
The type of video board or connecting cable used may not allow for correct displays adjustment of Horizontal Position,
Vertical Position, Horizontal Clock and Clock Phase.
●
The unit differentiates the signal modes according to the horizontal and vertical frequencies and the horizontal and
vertical sync signal polarities. Note that different signals having all these elements alike may be handled as the same
signal.
●
Displaying images with more than 768 lines of vertical resolution a Full display (compressed display) can result in the
interpolation of stripes.
