44
PRODUCT SPECIFICATIONS (continued)
Recommended Signal List
With Component Video INPUT
Signal mode
No
Signal
name
Resolution
Vertical
frequency
(Hz)
Horizontal
frequency
(kHz)
Dot clock
frequency
(MHz)
Remarks
1 576i 720(1440) x 576 50.00 15.63 27.00 EIA-861D
2 480i 720(1440) x 480 59.94 15.73 27.00 EIA-861D
3 576p 720 x 576 50.00 31.25 27.00 EIA-861D
4 480p 720 x 480 59.94 31.47 27.00 EIA-861D
5 1080i/50 1920 x 1080 50.00 28.13 74.25 EIA-861D
6 1080i/60 1920 x 1080 60.00 33.75 74.25 EIA-861D
7 720p/50 1280 x 720 50.00 37.50 74.25 EIA-861D
8 720p/60 1280 x 720 60.00 45.00 74.25 EIA-861D
With HDMI INPUT
Signal mode
No
Signal
name
Resolution
Vertical
frequency
(Hz)
Horizontal
frequency
(kHz)
Dot clock
frequency
(MHz)
Remarks
1 VGA 640x480 59.94 31.47 25.18 EIA-861D
2 576i 720(1440)x576 50.00 15.63 27.00 EIA-861D
3 480i 720(1440)x480 59.94 15.73 27.00 EIA-861D
4 576p 720x576 50.00 31.25 27.00 EIA-861D
5 480p 720x480 59.94 31.47 27.00 EIA-861D
6 1080i/50 1920x1080 50.00 28.13 74.25 EIA-861D
7 1080i/60 1920x1080 60.00 33.75 74.25 EIA-861D
8 720p/50 1280x720 50.00 37.50 74.25 EIA-861D
9 720p/60 1280x720 60.00 45.00 74.25 EIA-861D
10 1080p/50 1920x1080 50.00 56.25 148.50 EIA-861D
11 1080p/60 1920x1080 60.00 67.50 148.50 EIA-861D
12 1080p/24 1920x1080 24.00 27.00 74.25 EIA-861D
