18
– English
Check the transmission’s air intake
Check that the transmission’s air intake in not
blocked.
Check the transmission’s oil level
1. Check the transmission’s oil level by looking
through the mesh on the air intake. The oil level
should lie between the MIN and MAX markings
on the oil canister at 20° C.
If oil needs to be added the transmission cover
must be dismantled first. Release the two
screws (one on each side) and then lift off the
transmission cover.
MAINTENANCE
2. Screw off the oil canister cap and top up with
engine oil SAE 10W/30, class CD–CF, until the
oil level reaches the MAX marking. Screw the oil
canister cap back on, and fit the transmission
cover.
