SECTION 9:
SPECIFICATIONS
Input Voltage
9-12V dc
Power
6W
Controls
Push-button switches with backlit LCD display
Rate-proportional 3-axis joystick
Pan/Tilt Functions
Pan left, pan right, tilt up, tilt down
Zoom Lens Functions
Zoom in, Zoom out, Focus near, Focus far, Iris open, Iris close
Control Ports
RJ-12 connector with 1xRS-485 and 1xRS-232 port
Communication speed
RS-232: 1200 baud
RS-485: 9600 baud
Control Output Modes
RS-232 for Multiplexers and VCRs
RS-485 for Domes and PTZs
Operating Distances
4000 feet (219m) with RS-485 and 32 devices
50 feet (12.7m) maximum with RS-232
Ambient Temperatures
32°F to 122°F (0°C to 50°C)
Ambient Humidity
0~95% (non-condensing)
Construction
Extruded aluminum
Finish
Light gray powder coating
Dimensions
13W x 3.75H x 6.875D inches
(330W x 95H x 175D mm)
Weight
3 lbs (1.36 kg)
