Hitachi L2002 - Manual (Page 61)

L200
2
Inverter
In
v
e
rt
er Mounting
and Installation
2–15
Dimensional drawings, continued...
2-
φ5(0.20)
205(
8
.07)
H=220(
8
.66)
H=250(9.
8
4)
205(8.07)
205(8.07)
205(8.07)
205(8.07)
250(9.84)
250(9.84) -055LFU2
-055HFU2
-075LFU2
-075HFU2
-055HFEF2
-075HFEF2
H Model
164(6.46)
180(7.09)
7(0.16)
6.5(0.25)
6(0.24)
5.5(0.22)
155(6.10)
6(0.24)
L200–055LFU2, –055HFU2, –075LFU2, -075HFU2, –055HFEF2, -075HFEF2
