Intelligent Terminal Listing
Oper
ations
and Monitor
ing
4–8
Intelligent Outputs
Use the following table to locate pages for intelligent output material in this chapter.
S-ST 53 Special-Set Second Motor 4–17
Intelligent INPUTS
Symbol Code Name Page
Intelligent OUTPUTS
Symbol Code Name Page
RUN 00 Run Signal 4–38
FA1 01 Frequency Arrival Type 1 – Constant Speed 4–39
FA2 02 Frequency Arrival Type 2 – Over-frequency 4–39
OL 03 Overload Advance Notice Signal 4–41
OD 04 Output Deviation for PID Control 4–42
AL 05 Alarm Signal 4–43
Dc 06 Analog Input Disconnect Detect 4–45
FBV 07 Feedback Value Check 4–46
NDc 08 Network Detection Signal 4–49
LOG 09 Logic Output 4–50
ODc 10 Option Card Detection Signal 4–52
