ModBus Data Listing
Appendix B
B–42
Note 1: Assume that the inverter current rating is 10000 (for C041).
C143 Logic function select R/W Applies a logic function to
calculate [LOG] output state,
three options:
00 ... [LOG] = A AND B
01 ...[LOG] = A OR B
02 ...[LOG] = A XOR B
1152h 04434 0, 1, 2 —
C144 Terminal [11] ON delay R/W Range is 0.0 to 100.0 sec. 1153h 04435 0 to 1000 0.1 sec
C145 Terminal [11] OFF
delay R/W Range is 0.0 to 100.0 sec. 1154h 04436 0 to 1000 0.1 sec
C146 Terminal [12] ON delay R/W Range is 0.0 to 100.0 sec. 1155h 04437 0 to 1000 0.1 sec
C147 Terminal [12] OFF
delay R/W Range is 0.0 to 100.0 sec. 1156h 04438 0 to 1000 0.1 sec
C148 Output relay ON delay R/W Range is 0.0 to 100.0 sec. 1157h 04439 0 to 1000 0.1 sec
C149 Output relay OFF delay R/W Range is 0.0 to 100.0 sec. 1158h 04340 0 to 1000 0.1 sec
“C” Group Intelligent Terminal Functions
Func.
Code
Name R/W Description
Network Data
Register
Range Res.
hex dec.
