Intelligent input terminal overview – Hitachi L2002 User Manual
Page 129

L200
2
Inverter
Conf
igur
ing
Dr
iv
e P
a
ra
m
e
ters
3–49
NOTE: An input terminal configured for option code 18 ([RS] Reset command) cannot
be configured for normally closed operation.
Intelligent Input Terminal Overview
Each of the five intelligent terminals may be assigned any of the options in the following
table. When you program one of the option codes for terminal assignments C001 to
C005, the respective terminal assumes the function role of that option code. The terminal
functions have a symbol or abbreviation that we use to label a terminal using that
function. For example the “Forward Run” command is [FW]. The physical label on the
terminal block connector is simply 1, 2, 3, 4, or 5. However, schematic examples in this
manual also use the terminal symbol (such as [FW]) to show the assigned option. The
option codes for C011 to C015 determines the active state of the logical input (active
high or active low).
