ModBus Data Listing
Appendix B
B–20
Note 1:
ON usually when either the control circuit terminal board or a coil is ON.
Among intelligent input terminals, the control circuit terminal board is a high-
priority terminal. If the master cannot reset the coil ON status due to a trans-
mission line break, turn ON and OFF the control circuit terminal board to
make the coil OFF status.
Note 2:
The content of a transmission error is held until the error is reset. (The error
can be reset while the inverter is running.)
0013h
00019 (Reserved)
R
—
0014h
00020 Alarm signal
R
0..... Normal
1..... Trip
0015h
00021 PID deviation signal
R
0..... OFF
1..... ON
0016h
00022 Overload signal
R
0017h
00023 Frequency arrival signal
(set frequency or above)
R
0018h
00024 Frequency arrival signal
(at constant speed)
R
0019h
00025 Run Mode signal
R
001Ah 00026 Data writing
R
0..... Normal status
1..... Writing
001Bh 00027 CRC error
R
0..... No error *2
1..... Error
001Ch 00028 Overrun error
R
001Dh 00029 Framing error
R
001Eh
00030 Parity error
R
001Fh
00031 Check sum error
R
List of Coil Numbers
Coil Number
Name
R/W
Description
hex
dec.
