HP Compaq Business PC dc7600 - Manual (Page 49)

Convertible Minitower
System Configuration The Energy Consumption and Declared Noise Emissions data for the Convertible Minitower is
based on a typically configured model:
Processor 2.8 GHz
Memory 256 MB
Hard drive 80 GB
Energy Consumption 115 VAC 230 VAC 100 VAC
Normal Operation 80 W 76 W 80 W
Sleep 3.6 W 4.1 W 3.5 W
Off 1.4 W 1.9 W 1.4 W
Heat Dissipation** 115 VAC 230 VAC 100 VAC
Normal Operation 274 BTU/hr 260 BTU/hr 274 BTU/hr
Sleep 12 BTU/hr 14 BTU/hr 12 BTU/hr
Off 5 BTU/hr 6 BTU/hr 5 BTU/hr
NOTES:
* Energy Star low energy mode
** Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for
one hour.
This product is in compliance with US executive order 13221, WOL (wake on LAN) disabled.
Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296) Sound Power
(LWad, bels)
Deskside
Sound Pressure
(LpAm, decibels)
Idle 4.2 25
Fixed Disk
(random writes)
4.4 27
Optical Drive
(sequential reads)
4.8 31
Longevity and
Upgrading This product is designed to be upgraded, possibly extending its useful life by several years. Spare
parts are available throughout the warranty period and for up to 5 years after the end of
production. Upgradeability features contained in the product include:
Intel LGA775 processor socket
8 USB ports
4 multi-bay ports (optional)
4 empty PCI slots (2 standard, 2 low profile))
2 internal drive slots
4 memory slots
1 Serial Port (optional)
Batteries This product complies with ISO standards:
EU Directive 91/ 157/ EEC
EU Directive 93/ 86/ EEC
EU Directive 98/ 101/ EEC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
Lead greater than 4000ppm by weight.
Battery size: CR2032 (coin cell)
QuickSpecs
HP Compaq dc7600 Business PC
Technical Specifications - Environmental Data
DA - 12253 Worldwide QuickSpecs — Version 24 — 4.6.2006 Page 49
