Serviceability Features of System
Dual Color Power LED on Front of Computer (Indicates Normal Operations and Fault Conditions)
Diagnostic LED Explanation Table
Number of 1-second red LED blinks followed by 2-second pause, then repeats:
2-processor thermal protection activated
3-processor not installed
4-power supply failure
5-memory error
6-video error
7-PCA failure (ROM detected failure prior to video)
8-invalid ROM, bootblock recover mode
System/Emergency ROM Flash ROM CMOS Battery Holder for easy
Replacement
Flash Recovery with Video
Configuration Record SW 5 Aux Power LED on System PCA Processor ZIP Socket for easy
Upgrade
Over-Temp Warning on Screen
(Requires IM Agents) Clear Password Jumper DIMM Connectors for easy Upgrade
OS CD (Restore OS CD) Clear CMOS Button NIC LEDs (integrated) (Green &
Amber)
Restore CD
Serviceability Features of Chassis
Dual Color Power and HD LED
– To Indicate Normal
Operations and Fault
Conditions Color coordinated cables and
connectors Tool-less Hood Removal
Front power switch System memory can be upgraded
without removing the system board
or any internal components Tool-less Hard Drive, CD & Diskette
Removal
Green Pull Tabs, and Quick
Release Latches for easy
Identification Tool-less System Board Removal
NOTE: Thumb screw release mechanism is used with the Ultra-slim Desktop chassis cover.
Feature Description
ASF 2.0 support (Alert Standard
Format) Industry-standard specification for network alerting in operating system-absent
environments
Towerable Product can be oriented as a tower (in addition to desktop orientation)
Drive Self Tests (DPS) Drive Protection System
A diagnostic hard drive self test. It scans critical physical components and every
sector of the hard drive for physical faults and then reports any faults to the
user.
Running independently of the operating system, it can be accessed through a
Windows-based diagnostics utility or through the computer's setup procedure. It
produces an evaluation on whether the hard drive is the source of the problem
and needs to be replaced.
The system expands on the Self-Monitoring, Analysis, and Reporting
Technology (SMART), a continuously running systems diagnostic that alerts the
user to certain types of failures
DPS Access through F10 Setup
during Boot
SMART Technology
(Self-Monitoring, Analysis and
Reporting Technology) Allows hard drives to monitor their own health and to raise flags if imminent failures
were predicted
Predicts failures before they occur. Tracks fault prediction and failure indication
parameters such as re-allocated sector count, spin retry count, calibration retry
count
By avoiding actual hard drive failures, SMART hard drives act as "insurance"
against unplanned user downtime and potential data loss from hard drive failure
SMART I – Drive Failure Prediction
SMART II – Off-Line Data Collection
QuickSpecs
HP Compaq dc7600 Business PC
Technical Specifications
