DVI ADD2 Graphics Models DY674A Intel DVI ADD2 adapter for Convertible Minitower and Small
Form Factor
Form Factor Low-profile card
DVI-D Connector Compliant with DDWG (Digital Display Working Group) and VESA
specifications for a single-link digital DVI (DVI-D) connector.
Dual Head Support Yes, when used with the integrated VGA connector
Display Devices
Supported HP L1530
HP L1740
HP L1755
HP L1940
HP L1955
HP L2035
HP L2335
NOTE: The DVI ADD2 card offers optimal performance with any display that meets applicable
VESA standards.
Color Depth All modes support 8-bpp, 16-bpp, and 24-bpp color depths (up to 16.7
million colors)
Host Interface
Connector Mechanically compliant with PCI-E standard
Complies with the Intel ADD2 and Intel Serial Digital Video Output
(SDVO) specifications
Dot Clock 165 MHz maximum
Display Modes Supports display modes that require up to 165-MHz bandwidth on the
link, as shown in the following table.
Resolution 60-Hz LCD 60-Hz 75-Hz 85-Hz
Blanking 5% reduced GTF GTF GTF
640 x 480 VGA Yes Yes Yes Yes
800 x 600 SVGA Yes Yes Yes Yes
1024 x 768 XGA Yes Yes Yes Yes
1280 x 1024 SXGA Yes Yes No No
1600 x 1200 UXGA Yes Yes No No
ATI RADEON X300 SE
PCI Express (PCIe x16)
Graphics Models ATI RADEON X300 SE PCI Express 128-MB DDR single head DVI with
TV out
Bus Type PCI Express (x16 lanes)
Maximum Vertical
Refresh Rate 85 Hz
Display Support Integrated 400MHz RAMDAC
Display Max Resolution2048 x 1536
Board Display Options 128 MB Card Display Option
DVI-I + TV
DVI-I supports analog CRT or flat panel or digital flat panel (using DVI-
A, DVI-D or DVI-I connector)
DVI-I supports analog CRT or flat panel (with VGA connector and DVI-I
to VGA dongle)
TV Connector is a 7-pin mini-DIN (also allowing 4-pin S-Video without
adaptor)
Board Configuration
128 MB Frame Buffer Specification Description
Graphics Chip RADEON X300 SE PCI Express
Core clock 200 MHz
Memory clock 200 MHz
QuickSpecs
HP Compaq dc7600 Business PC
Technical Specifications - Graphics
DA - 12253 Worldwide QuickSpecs — Version 24 — 4.6.2006 Page 25
