8
3. KM-630MRH
Note: We reserve the right to make changes in specifications and design without prior notice.
AC SUPPLY VOLTAGE 208-230/60/1 (3 wire with neutral for 115V)
AMPERAGE 6.5 A ( 5 Min. Freeze AT 104°F / WT 80°F)
MINIMUM CIRCUIT AMPACITY 15 A
MAXIMUM FUSE SIZE 15 A
APPROXIMATE ICE PRODUCTION Ambient WATER TEMP. (°F)
PER 24 HR. Temp.(°F) 50 70 90
lbs./day ( kg/day ) 70 *603 (274) 573 (260) 531 (241)
Reference without *marks 80 580 (263) 532 (242) 491 (223)
90 573 (260) *499 (226) 457 (207)
100 564 (256) 489 (222) 418 (190)
SHAPE OF ICE Crescent Cube
ICE PRODUCTION PER CYCLE 14.3 lbs. (6.5 kg) 720 pcs.
APPROXIMATE STORAGE CAPACITY N/A
ELECTRIC & WATER CONSUMPTION 90/70°F 70/50°F
ELECTRIC W (kWH/100 lbs.) 1414 (6.8) 1332 (5.3)
WATER gal./24HR (gal./100 lbs.) 166 (33.3) 323 (53.6)
EXTERIOR DIMENSIONS (WxDxH) 22" x 27-1/2" x 37-1/2" (560 x 695 x 950 mm)
EXTERIOR FINISH Stainless Steel, Galvanized Steel (Rear)
WEIGHT Net 154 lbs. ( 70 kg ), Shipping 185 lbs. (84 kg)
CONNECTIONS - ELECTRIC Permanent - Connection
- WATER SUPPLY Inlet 1/2" FPT
- DRAIN Outlet 3/4" FPT
3/8" OD Pipe
CUBE CONTROL SYSTEM Float Switch
HARVESTING CONTROL SYSTEM Hot Gas and Water, Thermistor and Timer
ICE MAKING WATER CONTROL Timer Controlled. Overflow Pipe
COOLING WATER CONTROL N/A
BIN CONTROL SYSTEM Proximity Switch with Delay
COMPRESSOR Hermetic, Model RS64C1E-CAV
CONDENSER Air-cooled Remote, Condenser Unit URC 6F
EVAPORATOR Vertical type, Stainless Steel and Copper
REFRIGERANT CONTROL Thermostatic Expansion Valve
Condensing Pressure Regulator on URC-6F
REFRIGERANT CHARGE R-404A, 4 lb. 4 oz. ( 1950 g )
( Icemaker 2 lbs. 6 oz. Cond. 1 lbs. 14 oz.)
DESIGN PRESSURE High 467 PSIG, Low 230 PSIG
P.C. BOARD CIRCUIT PROTECTION High Voltage Cut-out ( Internal )
COMPRESSOR PROTECTION Auto-reset Overload Protector ( Internal )
REFRIGERANT CIRCUIT PROTECTION Auto-reset High Pressure Control Switch
LOW WATER PROTECTION Float Switch
ACCESSORIES -SUPPLIED N/A
-REQUIRED Ice Storage Bin
OPERATING CONDITIONS VOLTAGE RANGE 187 - 253 V
AMBIENT TEMP. 45 -100° F
WATER SUPPLY TEMP. 45 - 90° F
WATER SUPPLY PRESSURE 10 - 113 PSIG
