REAR PANEL JACKS FOR 35UX60B
25
NOTE: Model 35TX10B has only one antenna input, no external speaker output
connection and no Audio/Video output jacks.
NOTE: DOLBY SURROUND SPEAKER connection is used for Dolby surround. There is
always a signal coming out from this connection.
INT/EXT SPEAKER connection is connected in parallel with the factory built in speaker. By
using an optional external speaker, you can select to use which speaker you want by
switching the switch located at the rear panel to (INT) Internal for Factory built in speaker or
(EXT) External for optional consumer connected speakers, this is On Screen Display
controlled either "ON" or "OFF"
