FRONT PANEL JACKS AND CONNECTIONS
23
FRONT PANEL JACKS AND CONNECTIONS
The front panel jacks are provided as a convenience to allow you to easily connect a
camcorder or VCR as shown in the following examples:
Front Panel Jacks Examples
NOTE: Completely insert the connections cord plugs when connecting to front panel jacks.
If you do not, the played back picture may be abnormal. If you have an S-VHS VCR, use
the S-INPUT cable in place of the standard video cable. Model 35TX10B does not have
Front Panel S-Video connector.
