REAR PANEL JACKS FOR 35UX60B
24
REAR PANEL JACKS FOR 35UX60B
Rear Panel Jacks - 35UX60B
Antenna Inputs/Output
The "ANT" button on the Genius Remote Control allows you to switch between two
separate 75-ohm RF antenna inputs, Main (VHF/UHF) and Auxiliary (AUX). The
antenna output labeled "To converter" allows the Main (VHF/UHF) antenna connection
to pass directly to a different source such as a pay-TV cable decoder.
Audio/Video Inputs 1, 2
The "AVX" (Auxiliary Video) button will step through each video source and the current
antenna input each time it is pressed. Use the audio and video inputs to connect
external devices, such as VCR's, camcorders, laser disc players, video games, etc.
Output
These jacks provide fixed audio and video signals which are used for recording.
Audio to Hi-Fi
These jacks provide variable audio output to a separate stereo system amplifier. With
this connection, the audio to the stereo can be controlled by the television's remote
control. Use these jacks for the SURROUND Left and Right channels. (See page 19, 23
and 24)
Rear Speaker Terminals
These terminals are used to connect external speakers, which are used for the surround
sound feature. The volume level is controlled by the remote control main volume
buttons and also by an independent rear volume feature found in the "sound" function
menu. Use speakers with 8 Ohm impedance only. Terminals are Dolby external speaker
and switchable Internal/External Speakers.
S-Video
Input 1 provides S-Video (Super Video) jacks for connecting equipment with S-Video
output capability.
