NOTE:

NOTE: Product conformance to cited product specifications is based on
sample (type) testing, evaluation, or assessment. This product or family of
products is eligible to bear the appropriate compliance logos and
statements.

Smart Array P410i

Smart Array P410i
Controller

Controller

Dimensions

Dimensions
(not including bracket)

Low Profile PCIe Form Factor
7.5 in x 9.5 in x 2.25 in (19.05 cm x 24.13 cm x 5.72 cm)

Disk Drive and Enclosure

Disk Drive and Enclosure
Interface - Transfer rate

Interface - Transfer rate

3G SAS (Serial Attached SCSI)/6G SAS Capable

1.5G SATA (Serial ATA)/3G SATA Capable

SAS Connectors

2 internal (Mini-SAS) x8 wide port connectors

Cache Memory Speed

DDR2-800MHz with 40 or 72-bit wide bus provides up to 4.2 GB/s
maximum bandwidth.

Server Interface

x8 5G PCIe 2.0 provides 4GB/s maximum bandwidth

SAS Speed

x8 3G SAS provides 2.4GB/s maximum bandwidth

Cache Memory

40-bit 256MB ECC protected cache (72-bit 512MB BBWC module
upgrades available); transportable with battery-backed upgrade

Logical Drives Supported

Logical Drives Supported Up to 12 logical drives

Maximum Logical Drive

Maximum Logical Drive
Capacity

Capacity

Greater than 2TB

Host Memory Addressing

Host Memory Addressing 64-bit, supporting greater than 4GB server memory space

RAID Support

RAID 6, 6+0 (Advanced Data Guarding)

NOTE:

NOTE: The minimum of 256 MB cache, battery kit, and Smart Array
Advanced Pack License Key upgrade is required to enable RAID 6, 6+0

RAID 5, 5+0 (Distributed Data Guarding)

NOTE:

NOTE: The 256 MB & Battery Kit upgrade is required to enable RAID 5,
5+0 support of the Smart Array P410i

RAID 1+0 (Striping & Mirroring)

RAID 0 (Striping)

Upgradeable Firmware

Upgradeable Firmware with recovery ROM feature

QuickSpecs

HP ProLiant DL370 Generation 6 (G6)

HP ProLiant ML370 Generation 6 (G6)

Technical Specifications

DA - 13242 Worldwide — Version 3 — April 2, 2009
