HP Scanjet 8270 - Manual (Page 18)

4. If you are scanning a negative strip that has fewer than four frames, insert the
negative light-shield into the negative holder until it touches the negative strip.
Note Inserting the negative light-shield prevents stray light on the
scanned image.
5. Click the Scan Picture button ( ).
The HP Scanning dialog box is displayed.
6. Select Picture.
7. Select Scan negatives using the Transparent Materials Adapter (TMA).
If you want to preview the scanned image, select the Show Preview check box
on the screen, or begin the scan from HP Solution Center.
8. Click Scan.
9. Follow the instructions on the screen to finish scanning.
The scan is sent to the destination selected in the HP Scanning dialog box.
10. When finished, remove the negative strip. Replace the negative holder, the
negative light-shield, and the TMA cover.
Chapter 3
16 HP Scanjet 8270 Document Flatbed Scanner
