10 A, 15 A, 30A
92
TAKING CARE OF UNEXPECTED PROBLEMS
FUSE CASE LID
FUSE PULLER
‘‘90A’’MARK
FUSE (90A)
SPARE FUSE (90A)
ACG Fuse
Never use a f use with a rating
greater than specif ied. Serious
damage to the electrical system could
result.
Use the fuse puller from the tool
kit to remove the fuses. If a fuse is
blown, install a replacement fuse
of the same specified rating. The
outboard motor is supplied with
spare fuses in the fuse holder.
MAIN FUSE RATINGS:
Stop the engine and disconnect the
battery cable.
Remove the engine cover.
Remove the electrical parts cover.
Remove the fuse case lid.
Remove the old fuse by removing
two 5 mm screws. Reinstall the fuse case lid,
electrical parts cover and the
engine cover.
If fuses continue to blow, take the
outboard motor to an authorized
Honda marine dealer for inspection
and service or refer to the shop
manual.
If a blown fuse is found, try to
determine and correct the electrical
problem that caused the blown fuse.
An uncorrected electrical problem
may cause the fuse to blow again.
Reconnect the battery.
1.
2.
5.
6.
7.
3.
4.
5.
